GW4BVE/P HF Antenna

Approximate dimensions of my HF dipole. The balun has been omitted for simplicity and I now use RG316 feeder which I find is higher quality and of course has less loss, although as the feeder is so short the loss at HF is negligible. Please note that you should tune the antenna at the height you are going to use it on the hills. Make each section slightly longer and cut to minimum SWR starting at the highest frequency and working to the lowest. You will not get full coverage on 80m so it it is best cut for your preferred operational frequency.

这些天线通常架设在玻璃纤维伸缩式钓鱼杆上，更多图片请查看本页顶部的照片链接。

希望这能帮到你。

73 Mike GW0DSP
